TENGWAR - Enterprise RAG Platform

Problem & Context

Many organizations require internal knowledge assistants but cannot send proprietary documents to external LLM APIs due to legal, GDPR, trade secret, or IP protection requirements. TENGWAR is a plug-and-play on-premises solution that embeds company documents into vector databases and provides intelligent Q&A interfaces with precise source citations, all running locally on a single GPU node.

Responsibilities

• Full-stack architecture and implementation: backend API, desktop clients, web fallback, AI pipeline, and hardware configuration
• RAG architecture: hybrid search combining dense embeddings (BGE-M3), sparse vectors (BM25), and visual search with RRF fusion and cross-encoder reranking (BGE-Reranker-v2-m3)
• 14-phase smart document ingestion pipeline: structure detection (Docling), OCR (GLM-OCR), asset extraction, content fusion, context enrichment, translation (M2M-100), semantic chunking, tokenization, embedding, and vector storage
• Agentic chat system using Microsoft Agent Framework with autonomous tool invocation (document retrieval, web search, email, calendar, file generation)
• Real-time streaming responses via SignalR across all client surfaces
• Multi-layered security: JWT with RSA asymmetric signing, OAuth (Google + Microsoft Entra ID), RBAC, security clearance levels, department-based document filtering, per-user credential encryption (AES-256-GCM)
• Cross-platform desktop clients with .NET MAUI Blazor Hybrid (Windows + macOS)
• 15-service Docker Compose orchestration with GPU memory-sharing strategy for multiple vLLM services on a single NVIDIA GPU
• Multi-format document support: PDF, DOCX, XLSX, PPTX, TXT, MD, HTML, and more with automatic language detection and translation (100+ languages via M2M-100)

Architecture & Stack

• Backend: .NET 10 (C#), ASP.NET Core Web API, Entity Framework Core, SignalR hubs
• Desktop: .NET MAUI Blazor Hybrid (Windows + macOS native)
• Web: Blazor Server in Docker (browser-based fallback)
• Chat Model: vLLM serving Qwen3.5-35B-A3B-FP8 (35B total params, 3B active via MoE)
• Embeddings: BGE-M3 (568M, 1024-dimensional vectors)
• Reranker: BGE-Reranker-v2-m3 (cross-encoder)
• OCR: GLM-OCR 0.9B (vision-based document OCR)
• Translation: M2M-100 1.2B (100+ languages)
• Vector Database: Qdrant (dense + sparse + visual collections)
• Document Processing: Docling-based pipeline with semantic chunking
• Database: PostgreSQL 16
• Object Storage: MinIO (S3-compatible)
• Message Queue: RabbitMQ 3
• Web Search: SearXNG (self-hosted metasearch for agent tool)
• Deployment: Docker Compose (15 services), single NVIDIA GPU with precise memory allocation per vLLM service

Outcomes

• Enabled 100% private AI assistant for organizations unable to use cloud LLMs
• 14-phase intelligent ingestion pipeline with automatic OCR, translation, and semantic chunking eliminates manual document processing
• Hybrid search (dense + sparse + visual) with RRF fusion and cross-encoder reranking delivers precise, context-aware answers
• Agentic AI autonomously decides when to retrieve documents, search the web, or use other tools
• Multi-client support (Windows, macOS, Web) with shared Blazor UI layer ensures consistent experience
• Security model with clearance levels and department filtering meets enterprise compliance requirements
• Single-GPU deployment with memory-sharing strategy makes the platform accessible to SMBs without expensive infrastructure

Demo

Learn More

Official product page: tengwar.net ↗
